CQB150W-110S

150Watts 43-160VDC 4:1 Input Quarter Brick Railway DC-DC Converter

CQB150W-110S

150W Isolated Output

Efficiency up to 92%

Fixed Switching Frequency

4:1 Input Range

Regulated Outputs

Remote On/Off

Low No Load Power Consumption

Over Temperature Protection

Over Voltage/Current Protection

Continuous Short Circuit Protection

Quarter Brick Size Meet Industrial Standard

UL60950-1 2nd (Basic Insulation) Approval (Except 3.3 &15Vout)

CB Test Certificate IEC60950-1 (Except 3.3 &15Vout)

Meets EN50155 with External Circuits

Shock & Vibration Meets EN50155 (EN61373)

Fire & Smoke Meets EN45545-2

3000m Operating Altitude

Download File
Model List
Part Number Input Voltage Output Voltage Output Current No load Input Current Efficiency (%) I/O Isolation Voltage
CQB150W-110S3V3 43~160V 3.3V 30A 10mA 89 3000VDC
CQB150W-110S05 43~160V 5V 30A 10mA 91 3000VDC
CQB150W-110S12 43~160V 12V 12.5A 10mA 92 3000VDC
CQB150W-110S15 43~160V 15V 10A 10mA 91 3000VDC
CQB150W-110S24 43~160V 24V 6.3A 10mA 89 3000VDC
CQB150W-110S28 43~160V 28V 5.4A 10mA 89 3000VDC
CQB150W-110S48 43~160V 48V 3.2A 10mA 90.5 3000VDC
CQB150W-110S3V3N 43~160V 3.3V 30A 10mA 89 3000VDC
CQB150W-110S05N 43~160V 5V 30A 10mA 91 3000VDC
CQB150W-110S12N 43~160V 12V 12.5A 10mA 92 3000VDC
CQB150W-110S15N 43~160V 15V 10A 10mA 91 3000VDC
CQB150W-110S24N 43~160V 24V 6.3A 10mA 89 3000VDC
CQB150W-110S28N 43~160V 28V 5.4A 10mA 89 3000VDC
CQB150W-110S48N 43~160V 48V 3.2A 10mA 90.5 3000VDC
