New Release of Evaluation Board (EVB) for DC-DC Brick Converter
28
Sep
Sep 28, 2023
Cincon is glad to announce the new release of evaluation board for DC-DC brick converters. The evaluation boards are tools for users to run fast test of Cincon DC-DC brick converters. With the help of the evaluation boards, users would know more about the pin functions and the electrical properties of the DC-DC brick converters.
In addition, Cincon also provides detailed application notes including schematic, component placement, bill of materials and referred links to the application notes of related DC-DC converters for users. The following is the list for the products which have available evaluation boards.
Product List with Evaluation Boards:
| Railway DC-DC Converters | ||||
| Product | Power | Vin (Vdc) | Vo (Vdc) | Efficiency |
|
|
50W | 9~75V | 12V, 15V, 24V, 28V, 48V | 91% |
|
|
50W | 14~160V | 5V, 12V, 24V, 48V | 89% |
|
|
75W | 9~75V | 12V, 15V, 24V, 28V, 48V | 90% |
|
|
100W | 43~160V | 5V, 12V, 15V, 24V, 28V, 48V | 92% |
|
|
150W | 43~160V | 3.3V, 5V, 12V, 15V, 24V, 28V, 48V |
92% |
|
|
200W | 43~160V | 5V, 12V, 24V, 28V, 48V | 91% |
|
|
200W | 14~160V | 12V, 15V, 24V, 48V | 90% |
|
|
300W | 43~160V | 3.3V, 5V, 12V, 24V, 28V, 48V | 91% |
| High Input Voltage DC-DC Converters | ||||
| Product | Power | Vin (Vdc) | Vo (Vdc) | Efficiency |
|
|
75W | 180~450V | 3.3V, 5V, 12V, 15V, 24V, 48V | 90% |
|
|
150W | 180~425V | 5V, 12V, 15V, 24V, 28V, 48V | 89% |
|
|
300W | 180~425V | 5V, 12V, 24V, 28V, 48V | 90% |
|
|
750W | 200~425V | 12V, 15V, 24V, 28V, 36V, 48V | 91% |
If you’re interested in any evaluation board, contact your Cincon account manager directly for more details!
