CQB150-300S

150Watts Quarter Brick DC-DC Converter Input Voltage 180-425VDC

CQB150-300S

150W Isolated Output

Efficiency to 89%

Fixed Switching Frequency

Regulated Outputs

Remote On/Off

Low No Load Power Consumption

Over Temperature Protection

Over Voltage/Current Protection

Continuous Short Circuit Protection

Quarter Brick Size meet industrial standard

CE Mark Meets 2014/30/EU

UL60950-1 2nd (Reinforced Insulation) Approval

Download File
Model List
Part Number Input Voltage Output Voltage Output Current No load Input Current Efficiency (%) I/O Isolation Voltage
CQB150-300S05 180~425V 5V 30A 10mA 86 3000VAC
CQB150-300S12 180~425V 12V 12.5A 10mA 89 3000VAC
CQB150-300S15 180~425V 15V 10A 10mA 89 3000VAC
CQB150-300S24 180~425V 24V 6.3A 10mA 88.5 3000VAC
CQB150-300S28 180~425V 28V 5.4A 10mA 88.5 3000VAC
CQB150-300S48 180~425V 48V 3.2A 10mA 89 3000VAC
CQB150-300S05N 180~425V 5V 30A 10mA 86 3000VAC
CQB150-300S12N 180~425V 12V 12.5A 10mA 89 3000VAC
CQB150-300S15N 180~425V 15V 10A 10mA 89 3000VAC
CQB150-300S24N 180~425V 24V 6.3A 10mA 88.5 3000VAC
CQB150-300S28N 180~425V 28V 5.4A 10mA 88.5 3000VAC
CQB150-300S48N 180~425V 48V 3.2A 10mA 89 3000VAC
