Cincon Open Frame AC-DC switching power supplies module offers Connector type, Baseplate-cooled type and PCB mounting type, with power ranging from 6W to 500W, they are some of highest power density products in the current market. All products are approved for latest ITE safety or Medical safety. For some of our latest models, they meet EN/IEC 60335-1, and include a unique feature of 200% peak load feature. This special 200% peak load feature fulfills the need to customer sudden needs of power for a short period of time, and can now avoid choosing other products that are over-spec, save on cost and layout space/footprint consumption.

Cincon AC-DC switching power supply module introduction

For industrial, ITE, 5G telecom applications, there are Class I, Class II, and both Class I & Class II categories to choose. The power range of Class I power supplies starts from 20W to 300W. The power range of Class II power supplies starts from 6W to 60W. The power range of the category with both options starts from 80W, 130W, and 150W.



For medical application, there are three categories of “Class II”, “Class I” and “Class I & Class II”. The Class II medical power supply has only one 20W. In Class I category, the power range starts from 40W to 500W. For Class I & Class II category, the power output has 130W and 200W.

ITE/Industrial On-Board Open Frame

Model Power Input Voltage Output Voltage Features Dimensions (Inch) Datasheet Find stock RFQ
　　　 CFM04S CFM04S 4W 85-305 3.3V, 5V, 12V, 15V, 24V Altitude 5000m
Class II		 1.56x0.764x0.720
(PCB-mount)
1.62x0.83x0.787
(Encapsulated)
1.95.x0.71x0.689
(Wafer)		 Stock RFQ
　　　 CFM06S CFM06S 6W 90-264 3.3V, 5V, 9V, 12V, 15V, 24V Altitude 5000m
Class II		 1.555x0.764x0.720
(PCB-mount)
1.618x0.827x0.787
(Encapsulated)
1.950.x0.728x0.689
(Wafer)		 Stock RFQ
　　　 CFM12S CFM12S 12W 90-264 5V, 9V, 12V, 15V, 24V Altitude 5000m
Approval EN60335-1
Class II		 1.500x1.000x0.764
(PCB-mount)
1.600x1.1x0.772
(Encapsulated)
2.150x1.000x0.681
(Wafer)		 Stock RFQ
　　　 CFM20S CFM20S 20W 90-264 5V, 12V, 15V, 24V, 48V Altitude 5000m
Meets EN60335-1
Class II		 2.382x1.300x0.906
(PCB-mount)
2.482x1.402x0.933
(Encapsulated)
3.000x1.300x0.831
(Wafer)		 Stock RFQ
　　　 CFM25S CFM25S 25W 90-264 5V, 12V, 15V, 24V, 36V, 48V 2 Times Peak Load
Altitude 5000m
Approval EN60335-1
Class II		 2.000x1.100x0.980
(PCB-mount)
2.091x1.193x0.976
(Encapsulated)
2.776x1.100x0.906
(Wafer)		 Stock RFQ
　　　 CFM36S CFM36S 36W 90-264 5V, 12V, 15V, 24V, 48V Altitude 5000m
Class I & Class II		 3.00x1.50x1.100
(PCB-mount)
3.10x1.60x1.134
(Encapsulated)
3.00x1.50x1.000
(Wafer)		 Stock RFQ
　　　 CFM41S CFM41S 40W 90-264 5V, 12V, 15V, 24V, 36V, 48V 2 Times Peak Load
Altitude 5000m
Meets EN60335-1
Class II		 2.000x2.000x1.01
(PCB-mount)
2.14x2.14x1.035
(Encapsulated)
2.70x2.00x0.941
(Wafer)		 Stock RFQ
　　　 CFM61S CFM61S 60W 90-264 5V, 12V, 15V, 24V, 36V, 48V 2 Times Peak Load
Altitude 5000m
Class II
 2.00x2.00x1.398
(PCB-mount)
2.14x2.14x1.409
(Encapsulated)
2.70x2.00x1.343
(Wafer)		 Stock RFQ

ITE/Industrial Connector Open Frame

Model Power Input Voltage Output Voltage Features Dimensions (Inch) Datasheet Find stock RFQ
　　　 CFM40S CFM40S 40W 90-264 3.3V, 5V, 9V, 12V, 15V, 24V, 30V, 36V, 48V High Peak Load 4.000x2.000x1.275
(PCB-mount)
4.000x2.000x1.200
(Wafer)
4.606x2.441x1.575
(Cover)		 Stock RFQ
　　　 CFM40D/T CFM40D/T 40W 90-264 3.3V/5V/-12V, 5V/12V, 5V/12V/-12V, 5V/12V/-5V, 5V/15V/-15V, 5V/24V, 5V/24V/-12V, 5V/24V/-5V, 5V/24V/12V Dual & Triple Outputs 4.000x2.000x1.200
(Wafer)
4.606x2.441x1.575
(Cover)		 Stock RFQ
NEW CFM50S CFM50S 50W 85-264 5V, 12V, 15V, 24V, 36V, 48V Altitude 5000m
Meets EN60335-1
ClassⅠ& Class Ⅱ		 3.000x2.000x1.067 (Wafer)
3.000x2.00x1.142 (PCB Mount)
3.598x2.520x1.358 (Cover)		 Stock RFQ
　　　 CFM60S CFM60S 60W 90-264 3.3V, 5V, 9V, 12V, 15V, 24V, 30V, 36V, 48V High Peak Load 4.000x2.000x1.275
(PCB-mount)
4.000x2.000x1.200
(Wafer)
4.606x2.441x1.575
(Cover)		 Stock RFQ
　　　 CFM60T CFM60T 60W 90-264 3.3V/5V/-12V, 5V/12V/-12V, 5V/15V/-15V, 5V/24V/-12V Triple Outputs 4.000x2.000x1.260
(Wafer)		 Stock RFQ
NEW CFM70S CFM70S 70W 85-264 5V, 12V, 15V, 24V, 36V, 48V Altitude 5000m
Meets EN60335-1
ClassⅠ& Class Ⅱ		 3.000x2.000x1.067 (Wafer)
3.000x2.00x1.142 (PCB Mount)
3.598x2.520x1.358 (Cover)		 Stock RFQ
　　　 CFM80S CFM80S 80W 90-264 5V, 12V, 15V, 24V, 48V EN61000-3-2 Class A 4.000x2.000x1.142
(PCB-mount)
4.000x2.000x1.07
(Wafer)		 Stock RFQ
　　　 CFM81S CFM81S 80W 90-264 12V, 15V, 24V, 48V 2 Times Peak Load
Altitude 5000m
Approval EN60335-1
ClassⅠ& Class Ⅱ		 3.000x2.000x1.339 (Wafer)
3.200x2.441x1.575 (Cover)		 Stock RFQ

ITE/Industrial Baseplate-cooled Open Frame

Model Power Input Voltage Output Voltage Features Dimensions (Inch) Datasheet Find stock RFQ
　　　 CFM130S CFM130S 130W 80-264 12V, 18V, 19V, 24V, 36V, 48V Altitude 5000m
ClassⅠ& Class Ⅱ		 3.000x2.000x1.20 (Open-frame)
3.598x2.000x1.299 (Baseplate)
3.598x2.520x1.358 (Cover)		 Stock RFQ
　　　 CFM150S CFM150S 150W 90-264 12V, 24V, 28V, 36V, 48V Altitude 5000m
Class I & Class II
 4.00x2.00x1.283
(Open-frame)
4.60x2.00x1.362
(Baseplate)		 Stock RFQ
NEW LFM200S LFM200S 200W 85-264 12V, 15V, 24V, 28V, 30V, 36V, 48V, 54V Altitude 5000m
Meets EN60335-1
ClassⅠ		 Baseplate:3.04x2.00x1.00
Covered:3.09x2.28x1.00		 Stock RFQ
　　　 CFM202S CFM202S 200W 90-264 12V, 24V, 28V, 36V, 48V, 56V Altitude 5000m
Approval EN60335-1
ClassⅠ& Class Ⅱ		 4.000x2.000x1.311 (Baseplate)
4.598x2.520x1.358 (Cover)		 Stock RFQ
　　　 CFM260S CFM260S 260W 85-264 12V, 24V, 36V, 48V Altitude 5000m
Class I 		4.000x2.000x1.441
(Open-frame)
4.598x2.000x1.520
(Baseplate)
4.598x2.520x1.594
(Cover)		 Stock RFQ
NEW LFM300S LFM300S 300W 85-264 12V, 15V, 24V, 28V, 30V, 48V, 54V Altitude 5000m
Meets EN60335-1
ClassⅠ		 Baseplate:4.04x2.00x1.00
Covered:4.09x2.28x1.00		 Stock RFQ
　　　 CFM300S CFM300S 300W 90-264 12V, 24V, 36V, 48V Altitude 5000m
Meets EN60335-1
Class I 		5.000x3.000x1.421
(Baseplate)
5.355x3.425x1.591
(Cover)		 Stock RFQ
　　　 CFM400S CFM400S 400W 80-264 12V, 18V, 24V, 36V, 48V, 54V Altitude 5000m
Meets IEC/EN60335-1		 5.000x3.000x1.540
(Baseplate)
5.354x3.425x1.673
(Cover)		 Stock RFQ
NEW LFM420S LFM420S 420W 85-264 12V, 15V, 24V, 28V, 30V, 36V, 48V, 54V Altitude 5000m
Meets EN60335-1
ClassⅠ		 Baseplate:5.00x3.00x1.00
Covered:5.09x3.29x1.00		 Stock RFQ
　　　 CFM500S CFM500S 500W 80-264 12V, 18V, 24V, 28V, 30V, 36V, 48V Altitude 5000m
Meets EN60335-1
 5.000x3.000x1.540
(Baseplate)
5.354x3.425x1.673
(Cover)		 Stock RFQ

Medical Class II On-Board Open Frame

Model Power Input Voltage Output Voltage Features Dimensions (Inch) Datasheet Find stock RFQ
　　　 CFM21 CFM21 20W 90-264 3.3V, 5V, 9V, 12V, 15V, 24V 2MOOP
2.38x1.60x0.80
(PCB-mount)
3.00x1.60x0.77
(Wafer)
2.53x1.74x0.80
(Encapsulated)
3.00x1.60x0.77
(Screw Terminal)		 Stock RFQ

Medical Class I Connector Open Frame

Model Power Input Voltage Output Voltage Features Dimensions (Inch) Datasheet Find stock RFQ
　　　 CFM40M CFM40M 40W 90-264 3.3V, 5V, 9V, 12V, 15V, 24V, 30V, 36V, 48V 2MOPP 3.000x2.000x0.948
(PCB-mount)
3.000x2.000x0.909
(Wafer)
3.200x2.441x1.260
(Cover)		 Stock RFQ
　　　 CFM60M CFM60M 60W 90-264 5V, 12V, 15V, 24V, 48V 2MOPP
 4.000x2.000x1.100
(Wafer)
4.606x2.441x1.575
(Cover)		 Stock RFQ

Medical Baseplate-cooled Open Frame

Model Power Input Voltage Output Voltage Features Dimensions (Inch) Datasheet Find stock RFQ
　　　 CFM130M CFM130M 130W 80-264 12V, 18V, 19V, 24V, 36V, 48V 2MOPP
Altitude 5000m
Class I & Class II		 3.000x2.000x1.20
(Open-frame)
3.598x2.000x1.299
(Baseplate)
3.598x2.520x1.358
(Cover)		 Stock RFQ
NEW LFM200M LFM200M 200W 85-264 12V, 15V, 24V, 28V, 30V, 36V, 48V, 54V 2 MOPP
Altitude 5000m
Class I & Class II		 Baseplate:3.04x2.00x1.00
Covered:3.09x2.28x1.00		 Stock RFQ
NEW LFM300M LFM300M 300W 85-264 12V, 15V, 24V, 28V, 30V, 48V, 54V 2 MOPP
Altitude 5000m
Class I & Class II		 Baseplate:4.04x2.00x1.00
Covered:4.09x2.28x1.00		 Stock RFQ
　　　 CFM300M CFM300M 300W 90-264 12V, 24V, 36V, 48V 2MOPP
Class I		 5.000x3.000x1.421
(Baseplate)
5.355x3.425x1.591
(Cover)		 Stock RFQ
NEW LFM420M LFM420M 420W 85-264 12V, 15V, 24V, 28V, 30V, 36V, 48V, 54V 2 MOPP
Altitude 5000m
Class I		 Baseplate:5.00x3.00x1.00
Covered:5.09x3.29x1.00		 Stock RFQ
　　　 CFM500M CFM500M 500W 80-264 12V, 18V, 24V, 36V, 48V 2MOPP
Altitude 5000m
Meets EN60335-1
Class I & II		 5.000x3.000x1.540
(Baseplate)
5.354x3.425x1.673
(Cover)		 Stock RFQ
