EC7AW18
10Watts 18:1 Ultra-wide Input DIP-24 Isolated DC-DC CONVERTER
Efficiency up to 88%
Fixed Switching Frequency
Regulated Outputs
Remote On/Off
Low No Load Power Consumption
Fully protected (OCP/OVP/UVLO)
3000Vac I/O Isolation
Operating Ambient Temperature -40 to +100℃
1.25”x0.8”x0.5” Size Meet Industrial Standard
CB Test Certificate IEC62368-1
EN55032/EN55035/EN50155 Compliant with External Circuits
UL62368-1 3rd (Reinforced Insulation) Approval
Shock & Vibration EN50155 (EN61373) Compliant
Fire & Smoke EN45545-2 Compliant
5000m Operating Altitude
Datasheet| Part Number | Input Voltage | Output Voltage | Output Current | No load Input Current | Efficiency (%) | I/O Isolation Voltage | Package | Datasheet | Find stock | RFQ | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NEW | |
EC7AW18-72S05 | 8.5~160V | 5V | 2A | 6mA | 84 | 3000VAC | DIP24 |

|
  Stock |
  RFQ |
| NEW | |
EC7AW18-72S12 | 8.5~160V | 12V | 0.835A | 6mA | 88 | 3000VAC | DIP24 |
|
Stock |
RFQ |
| NEW | |
EC7AW18-72S15 | 8.5~160V | 15V | 0.668A | 6mA | 88 | 3000VAC | DIP24 |
|
Stock |
RFQ |
| NEW | |
EC7AW18-72D05 | 8.5~160V | ±5V | ±1A | 6mA | 83 | 3000VAC | DIP24 |
|
Stock |
RFQ |
| NEW | |
EC7AW18-72D12 | 8.5~160V | ±12V | ±0.416A | 6mA | 87 | 3000VAC | DIP24 |
|
Stock |
RFQ |
| NEW | |
EC7AW18-72D15 | 8.5~160V | ±15V | ±0.333A | 6mA | 87 | 3000VAC | DIP24 |
|
Stock |
RFQ |
