Cincon Releases CQB75W14 Series, New 75W Quarter Brick Size 14:1 Ultra-wide Input Range DC-DC Converter

Our brand new CQB75W14 series, a 14:1 ultra-wide input DC-DC converter, delivers 75W of regulated output power in a standard quarter brick size of 2.28 x 1.45 inches (57.8 x 36.8 mm). This series has safety approvals for IEC/UL 62368-1 and 3000Vac isolation (input to output).

#Product Press Release #DC-DC Converter #Railway #Industrial / ITE #Ultra-wide Input Range

07

Apr

Understanding The Power Supply De-Rating Specification

In general, for AC-DC power supplies and DC-DC converters, the recommended de-rating curves of output power are provided according to combination of various conditions such as operating voltage, temperature, or airflow. End-product designers could select power products based on this information. The de-rating operation is to ensure the safety the power system, heat dissipation performance, and reliability. Our clients are widely spread all over the world and the operating voltage, temperature, and environment of different markets differ. Therefore, it is essential to ensure the stability and reliability of power system. Violating the design rules and application conditions would have adverse effects on the life and reliability of power supply and end devices.

#Technical Article #AC-DC Power Supply #DC-DC Converter #Baseplate-cooling / Fanless

24

Mar

Cincon Releases CQB100W14 Series, New 100W Quarter Brick Size 14:1 Ultra-wide Input Range DC-DC Converter

The CQB100W14 series is our new 14:1 ultra-wide input DC-DC converter that provides 100W of regulated power in the industrial standard quarter brick size of 2.28 x 1.45 inches (57.9 x 36.8 mm). It has safety approvals for IEC/UL 62368-1 and 3000Vac isolation (input to output).

#Product Press Release #DC-DC Converter #Railway #Industrial / ITE #Ultra-wide Input Range

10

Mar

Introduction to POE Power Solution

Power over Ethernet, PoE, is a technology that simultaneously transmitting power and data to other devices through RJ45 in the Ethernet network. This technology is commonly applied to devices like Internet phones, wireless base stations, IP cameras, computer devices and other equipment that can be powered by Ethernet. The PoE equipment starts without power plug/socket, reducing the time and cost associated with power cord configuration, and therefore lowering the overall expense of the system.

#Technical Article #Featured Product Article #AC-DC Power Supply #DC-DC Converter #Industrial / ITE

03

Mar

Cincon Releases EC5DAW Series, New 10W 4:1 Input Range Compact Size DIP-16 Package DC-DC Converter

The EC5DAW series is our new 4:1 input range DC-DC converter that provides 10W of regulated power in the DIP-16 compact size of 0.95 x 0.54 inches (24.2 x 13.7 mm), saving the room of PCB for applications with critical limitation of space. The design of safety standard meets IEC/EN/UL 62368-1 and provides 3000VDC isolation (input to output).

#Product Press Release #DC-DC Converter #Industrial / ITE
