Cincon Releases CBM101S Series, New AC-DC 100W Brick Type Fanless Power Supply



#Product Press Release#AC-DC Power Supply#Industrial / ITE#Baseplate-cooling / Fanless

Nov 25, 2022



Key specs:

The CBM101S series is our new AC-DC brick type fanless power supply that provides 100W of regulated power in the full brick size and the 17 mm low profile package. The series has the safety approvals for IEC/UL/EN 62368-1 3rd edition.


The input range of CBM101S is from 90 to 264 VAC and possible for DC input which is from 120 to 370 VDC. This series is available in 5 outputs of 12, 24, 28, 36, 48 VDC, and available in class I. In addition, the CBM101S serves with the built-in EMI solution with EN 55032 Class B which could be the all-in-1 power solution for system engineers.


Exceptional Performance:

The power supply offers a low inrush current of 8.5A max. and a leakage current of 0.25mA max., an outstanding high efficiency up to 94.5%, and a very wide operating temperature range of -40°C to +85°C, which covers most of the harsh environments. Also, the CBM101S series provides the peak load operation up to 120W for 5 seconds. This power supply can be used at a high altitude up to 5000m max. and features a low no load input power consumption less than 0.5W. Moreover, the MTBF would be 600k hours.


Full Protections:

Safety approvals for IEC/UL/EN 62368-1 3rd edition.

EMC compliant to EN 55032 Class B and CISPR/FCC Class B.

This series is fully protected and offers output over current protection, output over voltage protection, over temperature protection, and continuous short circuit protection.



This AC-DC power supply is very suitable for a variety of industrial/ITE applications such as automation equipment, test & measurement instrument, commercial equipment, telecom and network devices, and more industrial applications. More importantly, the 0.67 inch (17 mm) height of the CBM101S is a great fit for applications with space or height limitation.
